Model:
T8Brand:
JINYINGProduct Parameter | Parameter Description |
JINYINGModel | T8 |
Product Name | Touch Screen Standalone Access Controller |
Card type | EM/MF |
Working voltage | DC12-24V |
Static Electricity | ≤35mA |
Reading Range | 2 ~ 5cm |
Ambient Temperature | -40~60℃ |
Humidity | 10%~90% |
Electric Lock Output | ≤1A |
Short-Circuit Protect | ≤100μS |
Relay Output Delay Time | 0-99 s |
Dimension | 86*86*20mm |
Unit Weight | 0.4KG |
Standard Package | 54PCS |
Carton Weight | 22.6KG |
Carton Size | 56*40*41cm |
