| Product Parameter | Parameter Description |
| JINYINGModel | PD-220D |
| Product Name | Industrial Grade Double Channel Vehicle Detector |
| Power Supply | 220VAC / 110VAC / DC12V / DC24V |
| Sensitivity | 9 leves adjustable |
| Working Frequency | about 100KHz |
| Detection Time | 35ms |
| Working Temperature | -40℃~ +65℃ |
| Working Humidity | Relative Humidity up to 95% |
| Lighting Protection Measures | Multiple Protection |
| Environmental Drift | Automatic Compensation |
| Storage Temperature | -40℃~ +85℃ |
| Installation Method | DIN rail |
| Dimensions | 110*60*100mm |
| Detection Channel | 2 |
| Output Mode | Double Relay |
| Delay Function | 0 ~ 4.5 seconds optional |
